Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length
  • Part Number: 52123001K
  • UP TO DATE INVENTORY: in stock In Stock Out of stock You can purchase this product but it's out of stock

Kifco E230 Water Reel Traveler 2.3”ID x 720’ Length

$29,828.00
design--v2
SEE IT ON YOUR PROPERTY

Our free design service helps determine the most cost effective and efficient reel for your property
free-shipping
FREE FREIGHT

We ship our reels fast & free from two locations to anywhere in the continental United States
banner
  • Barcode:




The NEW E230 is a one of a kind, American made traveler featuring a roller bearing turntable that allows for 180 degree rotation to irrigate in the opposite direction. The E230’s 3 wheel design can easily be towed around with your ATV or utility vehicle without the heavy tongue weight, eliminating the need for a dedicated tractor to deploy it.

The E230 features 2.3” ID x 720’ American made MDPE tube and a three-wheeled chassis with large flotation tires and easy to use crank jack stabilizer legs for stability. Fork pockets are built into the frame making loading and unloading this unit a breeze. With the same rugged and reliable construction that Kifco has included in our equipment since 1964, the E230 features automatic shutoff for unattended operation, a mechanical levelwind system to prevent kinking and mis-wraps for uniform tube rewinding, and a sprinkler selection valve which easily allows for automatic sprinkler shutoff at the end of the run.

The Kifco Model E230 uses a 4Hp gas engine to retract the sprinkler cart. Engine drives consume zero pressure and are capable of handling water supplies containing solids. The E230 operates as low as 44 psi and 51 gpm and features simple and accurate speed control.







  • Tube Inner Diameter/Length: 2.3” x 720’
  • Irrigated Width: 142’ - 229’
  • Irrigated Length: 791’ - 834’
  • Irrigated Area Per Run (Acres): 2.6 - 4.4
  • Drive System: Turbine
  • GPM Range: 51 - 147
  • Inlet PSI Range: 44 - 132
  • Hours Per Full Run: 9.6 - 18.4
  • Retraction Speed: 27 - 75 ft/hr
  • Dry Weight: 2,550 lbs
  • Weight With Water: 3,850 lbs
  • Inlet Diameter: 2” Male Camlock
  • Supply Hose: 15’ 2” Male x Female Camlock
  • Warranty: 1 Year Kifco Manufacturer Warranty

We package our Kifco Water Reels with everything you need to get started. With just a few easy to follow instructions you can be up and running right away.



  • E230 Water Reel
  • 15 foot 2" Supply Hose
  • Sprinkler Cart
  • Nelson SR75, Komet Twinmax
  • Nozzle & Decal Kit (INCLUDES ALL NOZZLES IN CHART FOR CHOSEN SPRINKLER)
  • Operating/Owner Manual
  • 1 Year Manufacturer Warranty Documentation
