Kifco E37 X 1220 Ag-Rain Water Reel 3.7
Kifco E37 X 1220 Ag-Rain Water Reel 3.7
Kifco E37 X 1220 Ag-Rain Water Reel 3.7
Kifco E37 X 1220 Ag-Rain Water Reel 3.7
Kifco E37 X 1220 Ag-Rain Water Reel 3.7
  • Part Number: 50406321KOMET
  • Realtime Availability: in stock In Stock Out of stock You can purchase this product but it's out of stock

Kifco E37 X 1220 Ag-Rain Water Reel 3.7" ID x 1220' Length

$57,646.00
design--v2
SEE IT ON YOUR PROPERTY
Our free design service helps determine the most cost effective and efficient reel for you property
purchase-order
Need to submit a purchase order? No problem, we accept them!

If you are school, university, municipality, government agency, or similar and need to use a purchase order please click here to fill out the form and we will send you a quote usually within the hour.

Once you receive your quote you can use it to submit your purchase order to sales@performancereel.com.
  • Barcode:

Gas Engine Driven Water-Reel® with 3.7” ID x 1220’ MDPE Tube. Portable, Simple, Reliable irrigation, waste water and slurry waste disposal or dust suppression. The UV resistant MDPE Tube is extremely durable and carries a 5 year pro-rated warranty against manufacturing defects. Rugged construction proven by over 40 years of production and over 35,000 Kifco Water-Reels® sold.

  • Efficient 4Hp gas powered engine for high travel speeds, waste water applications and low water pressure
  • Six gallon fuel cell
  • A two speed gearbox and three pulley settings provide six speed operation
  • Taky (Electronic Tachometer) which measures retraction speed, length of run, tube remaining and time to end of run
  • Liquid filled inlet pressure gauge
  • 30’ x 4” supply hose with 4” male ring lock supply end
  • Tube mis-wrap safety shutoff
  • Automatic shutoff of drive mechanism
  • Adjustable width guncart which allows for offset gun operation and added width for stability
  • Heavy duty hand crank stabilizer legs
  • Drawbar hitch for easy towing
  • Single axle heavy duty galvanized chassis
  • Adjustable width axle on chassis
  • Hand operated jack
  • Ball bearing turntable
  • Chain operated levelwind system
  • Speed compensation for consistent retraction speeds for entire length of run
  • Cross-Over Pipe allowing for water inlet on both sides of the reel
  • 1 Year Manufacturer Warranty Documentation
  • 5 Year Prorated Hose Warranty



  • Tube Inner Diameter/Length: 3.7” x 1220’
  • Irrigated Width: 210’ - 266’
  • Irrigated Length: 1,325’ - 1,353’
  • Retraction Speed: 60 - 400 ft. per hr.
  • Irrigated Area Per Run (Acres): 6.4 - 8.9
  • Drive System: Gas Engine
  • Fuel Cell Capacity (Gallons): 6 (approx. 37.5 hr. runtime)
  • GPM Range: 205 - 415
  • Inlet PSI Range: 69 - 141
  • Hours Per Full Run: 3.1 - 20.3
  • Dry Weight (lbs): 7,600
  • Weight w/ Water (lbs): 13,280
  • Chassis Size: ST6

We package our Kifco Water Reels with everything you need to get started. With just a few easy to follow instructions you can be up and running right away.

  • E37 x 1220 Ag Rain Water Reel
  • 30’ x 4” supply hose with 4” male ring lock supply end
  • Sprinkler Cart
  • Choice of Nelson SR 150 Big Gun or Komet 160 Ultra
  • Nozzle & Decal Kit (Size: 10mm, 12mm, 14mm, 16mm, 18mm)
  • Operating/Owner Manual
  • 1 Year Manufacturer Warranty Documentation
  • 5 Year Prorated Hose Warranty
