Kifco T25 X 750 Ag-Rain Water Reel Traveler 2.5" ID x 750' With Nelslon Sr100 & Kifco 23HP Self Priming Pump Package

KIFCO 23HP GAS PUMP & REEL HIGH PERFORMANCE PACKAGE

✓ Kifco T25 x 750 With Nelson Sr100

✓ 23HP High Pressure gas Kohler/Franklin Pump On Trailer

✓ Nozzle Kit (Size: .71", .77", .81", .86", .89", .93")

✓ 4" x 30' Suction Hose

✓ 4" Cast Foot Valve & Strainer

✓ 30' x 3" With 4" Ringlock Supply Hose

✓ High Pressure Shut-Down For Unattended Operation

The 23HP air-cooled engine driven gas primary pump is a perfect match for the T25 X 750. The pump will automatically shut down when the reel comes the end of the run so you can focus on more important things.

Our Kifco 23HP comes standard on a trailer and features electronic ignition, low flow shut-off, high temp blow off valve, fuel filter, air filters, muffler, choke and throttle to protect your investment and allow for safe operation

Turbine Driven Water-Reel® with 2.5” ID x 750’ MDPE Tube. Portable, Simple, Reliable irrigation for pastures, cash crops, reclamation, mining and construction sites, and large sports complexes. The UV resistent MDPE Tube is extremely durable and carries a 5 year pro-rated warranty against manufacturing defects. Rugged construction proven by over 40 years of production and over 35,000 Kifco Water-Reels® sold.

• Extremely efficient radial turbine provides retraction speed control
• A two speed gearbox and three pulley settings provide six speed operation
• Taky (Electronic Tachometer) which measures retraction speed, length of run, tube remaining and time to end of run
• Liquid filled inlet pressure gauge
• 30’ x 3” supply hose with 4” male ring lock supply end
• Tube mis-wrap safety shutoff
• Automatic shutoff of drive mechanism
• Chain operated level wind system
• Speed compensation for consistent retraction speeds for entire length of run
• Adjustable width gun cart for added stability
• Hand crank operated gun cart lift
• Heavy duty hand crank stabilizer legs
• Drawbar hitch for easy towing
• Single axle galvanized heavy duty chassis
• Hand operated jack
• Ball bearing turntable

• Tube Inner Diameter/Length 2.5” x 750’
• Irrigated Width 154’ - 207’
• Irrigated Length 831’ - 857’
• Retraction Speed 30 - 300 ft. per hr.
• Irrigated Area Per Run (Acres) 2.9 - 4.1
• Drive System Turbine
• GPM Range 74 - 177
• Inlet PSI Range 72 - 141
• Hours Per Full Run 1.9 - 18.9
• Dry Weight (lbs) 2,150
• Weight w/ Water (lbs) 3,100
• Chassis Size ST2

We package our Kifco Water Reels with everything you need to get started. With just a few easy to follow instructions you can be up and running right away.

• T25 x 750 Ag Rain Water Reel
• 23HP High Pressure gas Kohler/Franklin Pump On Trailer
• 3’ x 30” supply hose with 4” male ring lock supply end
• 4" x 30' Suction Hose
• 4" Cast Foot Valve/Strainer
• High Pressure Shut-Down
• Sprinkler Cart
• Nelson SR 100 Big Gun
• Nozzle & Decal Kit (.71", .77", .81", .86", .89", .93")
• Operating/Owner Manual
• 1 Year Manufacturer Warranty Documentation
• 5 Year Prorated Hose Warranty
