T27 X 980 Ag-Rain Water Reel23HP Pump Package
2.7" ID x 980'
- Stock #: 50406270-23HP
- Inventory: In Stock In Stock Out of stock You can purchase this product but it's out of stock
- Barcode:
Free FreightFast and free express freight in the continental U.S.
Free 24-Month Extended WarrantyExclusive full replacement coverage.
KIFCO 23HP GAS PUMP & REEL HIGH PERFORMANCE PACKAGE
✓ Kifco T27 x 980 With Nelson SR100 or Komet Twinmax
✓ 23HP High Pressure gas Kohler/Franklin Pump On Trailer
✓ Nozzle kit matched to your selected sprinkler
✓ 4" x 30' Suction Hose
✓ 4" Cast Foot Valve & Strainer
✓ 30' x 3" With 4" Ringlock Supply Hose
✓ High Pressure Shut-Down For Unattended Operation
The 23HP air-cooled engine driven gas primary pump is a perfect match for the T27 X 980. The pump will automatically shut down when the reel comes the end of the run so you can focus on more important things.
Our Kifco 23HP comes standard on a trailer and features electronic ignition, low flow shut-off, high temp blow off valve, fuel filter, air filters, muffler, choke and throttle to protect your investment and allow for safe operation
Turbine Driven Water-Reel® with 2.7” ID x 980’ MDPE Tube. Portable, Simple, Reliable irrigation for pastures, cash crops, reclamation, mining and construction sites, and large sports complexes. The UV resistent MDPE Tube is extremely durable and carries a 5 year pro-rated warranty against manufacturing defects. Rugged construction proven by over 40 years of production and over 35,000 Kifco Water-Reels® sold.
- Extremely efficient radial turbine provides retraction speed control
- A two speed gearbox and three pulley settings provide six speed operation
- Taky (Electronic Tachometer) which measures retraction speed, length of run, tube remaining and time to end of run
- Liquid filled inlet pressure gauge
- 30’ x 3” supply hose with 4” male ring lock supply end
- Tube mis-wrap safety shutoff
- Automatic shutoff of drive mechanism
- Chain operated levelwind system
- Speed compensation for consistent retraction speeds for entire length of run
- Adjustable width guncart for added stability
- Hand crank operated guncart lift
- Heavy duty hand crank stabilizer legs
- Drawbar hitch for easy towing
- Single axle galvanized heavy duty chassis
- Hand operated jack
- Ball bearing turntable

Specifications
- Tube Inner Diameter/Length: 2.7" x 980'
- Irrigated Width: 154'-203'
- Irrigated Length: 1057'-1082'
- Retraction Speed: 30 - 300 ft. per hr.
- Irrigated Area Per Run (Acres): 3.7 - 5.0
- Drive System: Turbine
- GPM Range: 74 - 152
- Inlet PSI Range: 71 - 128
- Hours Per Full Run: 3.3 - 32
- Dry Weight (lbs): 2800
- Weight w/ Water: (lbs) 4500
- Chassis Size: ST3
- 1 Year Kifco Warranty
- 5 Year Pro-Rated Hose Warranty
Charts
Pump curve
Product Downloads
PDFs open in a new tab to view, save or print.
What It Includes
We package our Kifco Water Reels with everything you need to get started. With just a few easy to follow instructions you can be up and running right away.
- T27 x 980 Ag Rain Water Reel
- 23HP High Pressure gas Kohler/Franklin Pump On Trailer
- 3’ x 30” supply hose with 4” male ring lock supply end
- 4" x 30' Suction Hose
- 4" Cast Foot Valve/Strainer
- High Pressure Shut-Down
- Sprinkler Cart
- Nelson SR100 or Komet Twinmax sprinkler (your selection)
- Nozzle & Decal Kit matched to your selected sprinkler
- Operating/Owner Manual
- 1 Year Manufacturer Warranty Documentation
- 5 Year Prorated Hose Warranty
